Products Description
Hydraulic Folding Tillage Implement for Medium Tractors
This folding disc harrow for small tractors belongs to the 1BJ hydraulic double-folding series and is perfectly matched with 75–100 HP medium tractors. Equipped with hydraulic retractable side wings, it drastically reduces transport width and solves the problem of wide-implement road transportation for Brazilian grain and sugarcane growers. It serves as an all-in-one tillage tool for pre-sowing soil preparation, straw burial, and land levelling.
High Output & Road-Friendly Structure
Fully unfolded, the 4.4m working width delivers productivity up to 2.7 hectares per hour. Hydraulic folding reduces the overall width without disassembly, making it compliant with highway and rural road width limits. Thickened 560mm steel discs crush hard clods and fully incorporate crop residues in a single pass.
Stable Traction & Cab Control System
The trailed design lowers the front axle load to avoid tractor overload during long shifts. Hydraulic depth adjustment can be operated from inside the cab for quick setup up to 140mm. Intuitive controls make operation accessible even for new farmers.
Specification
Standard Specification
|
Model |
Working Width |
Working Depth |
Disc Diameter |
Disc Count |
Matched HP |
Net Weight |
Hourly Productivity |
|
1BJ-4.4 (Core Model) |
4400 mm |
140 mm |
560 mm |
40 pcs |
75–100 HP |
1850 kg |
2.7 ha/h |
|
1BJ-5.3 |
5300 mm |
140 mm |
560 mm |
48 pcs |
100–120 HP |
2200 kg |
3.3 ha/h |
|
1BJ-6.0 |
6000 mm |
140 mm |
560 mm |
56 pcs |
100–120 HP |
2520 kg |
3.5 ha/h |
Application Fields
**Grain Farm Pre-Seed Land Prep**
Perfect for corn, soybean, and wheat fields. Breaks compacted soil, mixes straw residues, and levels uniform seedbeds for consistent germination.
**Brazilian Sugarcane Stubble Treatment**
Ideal for sugarcane plantations across Brazil. Efficiently cuts and buries cane stalks to boost organic matter and improve soil fertility.
**Scattered Medium Farms**
The foldable frame meets standard road-width restrictions, enabling safe transit between separated plots without additional transport trucks.
Core Advantages
Hydraulic Double-Folding Mechanism
Greatly narrowed transport width for easy movement on rural and public roads. No disassembly needed between fields.
Balanced Trailed Frame
Prevents overloading of 75–100HP medium tractors during continuous heavy tillage.
High Field Efficiency
Wide working span slashes total operating hours, cutting fuel and labor costs.
Heavy-Duty Steel Discs
High wear resistance extends service life and reduces spare-part replacement costs.
In-Cab Hydraulic Controls
Adjust folding angle and tillage depth with one-touch operation for maximum convenience.
Contact us Today
Our folding disc harrow for small tractors offers efficient, wide-width tillage with convenient road mobility for 75–100HP tractors. Sevol supplies factory-direct pricing, full technical sheets, and dedicated dealer support for Brazilian partners. Reach out for wholesale rates, bulk discounts, and container loading schemes!
