Products Description

PTO Rotating Discs Avoid Mud Blockage

Conventional passive disc ploughs often get stuck in sticky paddy mud, necessitating frequent stops for cleaning. This PTO-driven disc plough for paddy fields features actively rotating discs that smoothly slice through waterlogged soil and hardpan, enabling continuous field operation without repeated downtime.

All-in-One Paddy Bed Preparation

Equipped with 560mm discs rotating at 90–120 r/min, the machine reaches a tillage depth of 200–240mm. It completes soil breaking, straw mixing and ground levelling in a single pass. If buried rice straw decomposes rapidly, it will enrich soil organic matter and eliminate the need for multiple field trips before rice sowing or transplanting.

Waterproof Sealed Structure

All moving parts use fully sealed, waterproof bearings to block mud and rainwater intrusion, reducing the need for frequent daily lubrication and preventing bearing seizure in humid conditions. Meanwhile, the integrated welded steel frame delivers reliable structural strength for years of paddy cultivation. Universal three-point linkage allows quick mounting on most paddy tractors.

Specification

Standard Specification

Model	Disc Qty	Working Width	Working Depth	Matched HP	Net Weight
1YQ-320	3 pcs	660 mm	200–240 mm	15–18 HP	210 kg
1YQ-420	4 pcs	880 mm	200–240 mm	18–22 HP	240 kg
1YQ-522 (Core)	5 pcs	1100 mm	200–240 mm	25–40 HP	276 kg
1YQ-622	6 pcs	1320 mm	200–240 mm	40–50 HP	321 kg
1YQ-722	7 pcs	1540 mm	200–240 mm	50–60 HP	357 kg
1YQ-822	8 pcs	1760 mm	200–240 mm	60–80 HP	393 kg
1YQ-922	9 pcs	1980 mm	200–240 mm	80–90 HP	430 kg

Application Fields

**Pre-Sowing Tillage for Rice Paddies**

Uniform soft mud is critical for stable rice growth. This drive disk plough for paddy fields works well on both dried hardpan and waterlogged sticky mud. Smallholder farms can select 3/5-disc compact models, while large plantations adopt 8/9-disc units with a working width of nearly 2m for higher efficiency.

**Post-Harvest Rice Straw Incorporation**

Open straw burning causes environmental pollution and nutrient loss. This machine chops and fully buries rice residues in one run. Decomposed straw improves soil fertility and suppresses pest breeding for the next planting cycle.

**Waterlogged Lowland Reclamation**

Ordinary ploughs cannot process overgrown wet wasteland tangled with root clusters. Powered rotating discs cut through dense roots and compacted mud efficiently, turning idle wetland into productive rice fields within one growing season.

Core Competitive Advantages

• Active PTO Rotation Anti-Clog Design – Power-driven rotating discs maintain steady advance in heavy mud, cutting cleaning downtime and boosting daily field throughput compared to static passive ploughs.
• Long-Lasting Waterproof Bearing Assembly – Fully sealed bearing units resist corrosion under long wet-season operation, lowering machine breakdown rates and reducing long-term spare part costs for farmers and distributors.
• Complete Size Range for All Farm Sizes – A full lineup from 3 to 9 discs matches tractors of 15–90 HP, covering small family plots and large commercial rice plantations with flexible working width options from 660mm to 1980mm.

Sevol's drive disk plough for paddy fields is specifically designed to handle harsh, waterlogged paddy conditions where standard ploughs stall. Sevol provides factory-direct supply to global agricultural dealers. Feel free to contact us for wholesale pricing and full-container-load solutions.
